Deskripsi
GENERAL SPECS. :
- High lumen efficacy >145 lm/w
- Isolated LED driver
- Non dimmable
- Warranty 5 years
MECHANICAL SPECS. :
- Body material: full Al die casting
- Pole bracket dia. : 65mm (2″ pipe)
- Body thickness : avg. 3.2mm
- Dimension : 317x165x97mm (LxWxH)
- Weight : 1.8 kg +-200g
- Secondary lens/LED cover : PC
- Hardware : stainless steel SUS-304
- Painting : powder coating
- Ingress /Impact Protection : IP-66 /IK-08
ELECTRICAL SPECS. :
- LED Driver : Inventronics EUC-026
- Nominal input : 100 ~ 277Vac
- Operating Freq : 50/60Hz
- Rated Power : 20W
- Power Factor :>95%
- THD : <7%
- Surge Protection: 10KV
PHOTOMETRIC SPECS. :
- LED type : Lumileds/Luminus SMD 5050
- System Efficacy : >140 lm/w
- CCT (+_250K) : 5000K (CCT lain 3000/4000/5000K / 6500K tersedia sesuai permintaan)
- CRI : >70Ra
- Beam Angle : wide angle
ENVIRONMENT SPECS. :
- Operating temp. : -20 ~ 55oC
- Humidity : 10 ~ 90RH
